HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain - Free-Running Tanged Helical Inserts
HELI-COILFree-Running Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain

The HELI-COIL Helical Insert is a tanged tang-style, free-running insert with a 1/4"-20 thread size, right-hand orientation, and coarse thread pitch. Made from Nitronic 60 metal, it offers a tensile strength of…

SKU 3G-OTH-599091

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A1185-4EN625
Type
Free-Running, Plain, Plain, 100 PK
Thread Size
1/4"-20
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, free-running insert with a 1/4"-20 thread size, right-hand orientation, and coarse thread pitch. Made from Nitronic 60 metal, it offers a tensile strength of 200,000 psi and comes in a plain finish, 100-piece pack (MPN A1185-4EN625).

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces tapped threads in metal. It provides a strong, wear-resistant thread for fasteners in applications like automotive, aerospace, and industrial machinery. This free-running tanged style suits general-purpose thread repair.

What are the specifications of the HELI-COIL A1185-4EN625 insert?

This HELI-COIL insert has a 1/4"-20 thread size, coarse pitch, right-hand orientation, and a tensile strength of 200,000 psi. It is made from Nitronic 60 metal with a plain finish, comes in a 100-piece pack, and is designed for free-running, tanged tang-style installation.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this A1185-4EN625 insert to your facility. Contact us for a quote and delivery timeline to your location.

How to install a HELI-COIL tanged helical insert?

Install a HELI-COIL tanged insert by drilling out the damaged thread, tapping the hole to the specified size, then using a tang-style installation tool to wind the insert into place. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
