GE Molded Case Circuit Breaker: 30 A Amps, 14kA at 277/480V AC, Fixed, Lug - TEY-Frame GE Molded Case Circuit Breakers
GETEY-Frame GE Molded Case Circuit Breakers

GE Molded Case Circuit Breaker: 30 A Amps, 14kA at 277/480V AC, Fixed, Lug

The GE TEY-Frame Molded Case Circuit Breaker (MPN TEY230) is a 30 A, fixed instantaneous trip unit with a maximum AIR rating of 14kA at 277/480V AC. It features lug terminal connections and supports any phase…

SKU 3G-OTH-22953

Brand
GE
Item
Molded Case Circuit Breaker: 30 A Amps, 14kA at 277/480V AC, Fixed, Lug
Category
TEY-Frame GE Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
TEY230
Series
TEY
Max. AIR Rating
14kA at 277/480V AC
Phase Connection
Any
Instantaneous Trip
Fixed
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE TEY-Frame Molded Case Circuit Breaker (MPN TEY230) is a 30 A, fixed instantaneous trip unit with a maximum AIR rating of 14kA at 277/480V AC. It features lug terminal connections and supports any phase connection. This TEY-series breaker is designed for industrial overcurrent protection applications.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the GE TEY230 molded case circuit breaker used for?

The GE TEY230 is a 30 A molded case circuit breaker used for overcurrent protection in industrial electrical panels. It is designed for branch-circuit protection in commercial and industrial facilities, providing fixed instantaneous trip response and supporting any phase connection.

What are the specifications of the GE TEY230 circuit breaker?

The GE TEY230 is a TEY-series molded case circuit breaker rated 30 A with a maximum AIR rating of 14kA at 277/480V AC. It features a fixed instantaneous trip, lug terminal connections, and supports any phase connection. The manufacturer part number is TEY230.

Where to buy the GE TEY230 circuit breaker worldwide?

3G Electric supplies the GE TEY230 molded case circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this TEY-series breaker.

How to select the correct GE TEY230 circuit breaker for an application?

To select the GE TEY230, verify your system voltage (277/480V AC) and ensure the 30 A rating matches your load. Confirm the 14kA interrupting capacity is sufficient for available fault current. The fixed instantaneous trip and lug terminals suit standard industrial overcurrent protection needs.
