EATON Supplementary Protector: 2 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ - C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONC-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 2 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ

The EATON FAZ-C2/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 2 A. It carries a maximum AIR rating of 15 kA at 277/480 V AC and is also rated for 96 V DC. This IEC supplementary…

SKU 3G-OTH-21214

Brand
EATON
Item
Supplementary Protector: 2 A Amps, 96V DC, 15kA at 277/480V AC, Lug, FAZ
Category
C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C2/2
Series
FAZ
Type
15kA at 277/480V AC, Lug, FAZ, C
AC
277/480V
DC
96V
Curve Type
C
Max. AIR Rating
15kA at 277/480V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
96V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C2/2 is a C-curve, 2-pole UL1077 DIN rail-mount supplementary protector rated at 2 A. It carries a maximum AIR rating of 15 kA at 277/480 V AC and is also rated for 96 V DC. This IEC supplementary protector features lug terminals and is part of the FAZ series.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON c-curve, 2-pole ul1077 din rail-mount supplementary protectors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
