EATON Supplementary Protector: 25 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ - B-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATONB-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 25 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ

The EATON FAZ-B25/1-SP is a B-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated for 25 A. It carries a max. AIR rating of 15kA at 240/415V AC, with AC voltage ratings of 277/480V AC and a DC voltage…

SKU 3G-OTH-20517

Brand

EATON

Item

Supplementary Protector: 25 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ

Category

B-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

Available to Order

Trade pricing by quote — replies within 24h

Qty

WhatsApp an engineer

No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.

Create free account →Log in

Worldwide Shipping

Air & sea freight

Datasheet on Request

Technical specs

1-Day Quote

Replies within 24h

Technical Specifications

EATON

Manufacturer Part Number

FAZ-B25/1-SP

Series

FAZ

Type

15kA at 240/415V AC, Lug, FAZ, B

AC

277/480V

DC

48V

Curve Type

B

Max. AIR Rating

15kA at 240/415V AC

AC Voltage Rating

277/480V AC

DC Voltage Rating

48V DC

Terminal Connection

Lug

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

EATON Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-B25/1-SP is a B-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated for 25 A. It carries a max. AIR rating of 15kA at 240/415V AC, with AC voltage ratings of 277/480V AC and a DC voltage rating of 48V DC. This unit features lug terminal connections.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
