Dayton Exhaust Fan Venturi Frame: Steel, For 16 in Blade Dia
The Dayton Exhaust Fan Venturi Frame (MPN 10E034) is a steel frame designed for wall-mount ventilation fans with a 16-inch blade diameter and an 18 1/2-inch by 18 1/2-inch mounting size. This frame includes a slotted…
SKU 3G-OTH-83448
Need installation or engineering help?
Ask a question
Product Description
The Dayton Exhaust Fan Venturi Frame (MPN 10E034) is a steel frame designed for wall-mount ventilation fans with a 16-inch blade diameter and an 18 1/2-inch by 18 1/2-inch mounting size. This frame includes a slotted motor base for motor installation. It is constructed from steel for durability in industrial ventilation applications.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is the Dayton Exhaust Fan Venturi Frame used for?
The Dayton Exhaust Fan Venturi Frame (MPN 10E034) is a steel mounting frame for wall-mount ventilation fans with a 16-inch blade diameter. It provides a durable, secure housing that optimizes airflow in industrial exhaust applications, such as factories, warehouses, and commercial facilities.
What are the specifications of the Dayton 10E034 venturi frame?
The Dayton 10E034 venturi frame is made of steel and measures 18 1/2 inches by 18 1/2 inches. It is designed for a 16-inch blade diameter fan and includes a slotted motor base for easy motor installation. This frame is built for wall-mount ventilation systems in industrial settings.
Where to buy the Dayton 10E034 venturi frame worldwide?
3G Electric supplies the Dayton 10E034 venturi frame worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this steel fan frame for wall-mount ventilation.
How to install the Dayton venturi frame for a 16-inch fan?
To install the Dayton venturi frame, mount it securely to a wall opening sized for the 18 1/2-inch by 18 1/2-inch frame. Use the included slotted motor base to position and fasten the motor. Ensure the fan blade clears the frame interior for safe, efficient airflow in industrial exhaust systems.
Used in
Common applications for DaytonDayton Products
3G Electric supplies Dayton frames for wall-mount ventilation fans. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
