Euspray Flat jet nozzle type MC3E 1/8" index 04 angle 80° brass

Euspray MC3E flat jet nozzle delivers precise 80° spray coverage at 3.5 l/min (20 bar) with 1/8" brass construction. Ideal for industrial cleaning, coating, and humidification applications requiring controlled…

SKU 3G-CBM-06803

Also listed as: TEC 08006 · TEC-08006

Brand

Euspray

Item

Flat jet nozzle type MC3E 1/8" index 04 angle 80° brass

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Euspray

type

MC3E

angle

80°

index

04

material

brass

spray angle

80

connection size

1/8"

flow rate at 20bar

3.5 l/min

Datasheet Content

H3
                                                                                             H1
                                                                                                                      H2


                                                                                                          MC3E                  ✼ MC3E                          MC3
                                                                                                         Dimensioni mm Dimensions mm Dimensions mm
                                                                                                               Abmessungen mm Dimensiones mm
                                                                                       Ø                      H1                      ✼ H2                    H3
    1/8 MC3E                ✼ 3/8 MC3E                   3/8 MC3                       1/8                    17,0                    -                       -
    1/4 MC3E                                             1/2 MC3                       1/4                    19,5                    -                       -
                                                                                       3/8                    -                       15                      32
                                                         3/4 MC3                       1/2                    -                       -                       38
                                                                                       3/4                    -                       -                       50
                                                                                       1 - 1 1/4              -                       -                       60




                                                                                                                     TECHNISCHE
CARATTERISTICHE                       CHARACTERISTICS                         CARACTERISTIQUES                       EIGENSCHAFTEN                        CARACTERISTICAS
• Ugello a corpo unico                • One piece nozzle male                 • Buse en une seule pièce              • Einteilige     Düse      mit       • Boquillas en una sola
  attacco maschio.                      connection.                             Raccord mâle Angles de                 Außengewinde Lieferbare              pieza. Racord macho.
  Angoli di spruzzo dispo-              Available spray angles: 0°              dispersion disponibles:                Spritzwinkel: 0° - 15°- 25°-         Angulos de aspersión
  nibili: 0° - 15° - 25° -              - 15° - 25° - 40° - 50° -               0° - 15° - 25° - 40° - 50° -           40° - 50° - 65° - 80° - 95° -        posibles: 0° - 15°- 25°- 40°
  40° - 50° - 65° - 80° -               65° - 80° - 95° - 110°.                 65° - 80° - 95° - 110°.                110°.                                - 50° - 65° - 80° - 95°-
  95° - 110°.                                                                                                                                               110°.
                                      To order: specify nozzle code,          Pour commander faire suivre            Bei Bestellung Anschlußgewinde
Per ordinare far seguire al tipo      spray angle and material.               l’indice de débit par l’angle de       Düsentyp, Durchflußkennziffer,       Para efectuar al pedido añadir
scelto l’angolo di spruzzo e il       Ex.: 1/4 MC3E - 30/40° brass.           dispersion et le matériau.             Spritzwinkel und Werkstoff ange-     al diametro del racord el índi-
materiale.                                                                    Exemple: 1/4 MC3E - 30/40° lai-        ben. z.B. 1/4 MC3E - 30/40°.         ce del caudal, el ángulo de
Es.:1/4MC3E - 30/40° ottone.                                                  ton.                                                                        aspersión y el material.
                                                                                                                                                          Ejemplo: 1/4 MC3E - 30/40° laton.




APPLICAZIONI                          APPLICATIONS                            APPLICATIONS                           ANWENDUNGEN                          APLICACIONES
• Lavaggi industriali.                • Industrial washing.                   • Lavages industriels.                 • Industrielle Reinigung.            • Lavados industriales.
• Trattamento superficiale            • Metal surface treatings.              • Traitement de surface.               • Metalloberflächenbearbeitung       • Tratamiento de superficies.
  metalli.                            • Coal and gravel washing.              • Refroidissement.                     • Kühlung.                           • Enfriamiento.
• Lavaggio inerti.                    • Cooling.                              • Dégraissage.                         • Entfettung.                        • Desengrase.
• Raffreddamenti.                     • Degreasing.                                                                  • Kohlen- und Schlackenbe-           • Lavado inerte.
• Sgrassaggi.                                                                                                          feuchtung.
                            TIPO UGELLO                                                                  Pressione - Pressure - Pression - Druck - Presión (bar)
                            NOZZLE TYPE                                Ø1
                           TYPE DE BUSE                                            1        2        3        4         5       6        7       10      15        20        30      35
                             DÜSENTYP                                  mm
                         TIPO DE BOQUILLA                                                             Portata - Capacity - Debit - Volumenstrom - Caudal (l/min)

1/8 - MC3E - 03                     1/4 - MC3E - 03                     1.1       0.68      0.96     1.2      1.36     1.50     1.7      1.8      2.1     2.55       3.1     3.7     4.0
1/8 - MC3E - 04                     1/4 - MC3E - 04                     1.3       0.9       1.3      1.6      1.8      1.98     2.2      2.5      2.9     3.5        4.1     5.0     5.4
1/8 - MC3E - 06                     1/4 - MC3E - 06                     1.6       1.4       1.9      2.3      2.8      3.1      3.3      3.6      4.3     5.3        6.1     7.4     8.0
1/8 - MC3E - 08                     1/4 - MC3E - 08                     1.8       1.8       2.6      3.2      3.6      4.1      4.4      4.8      5.7     7.0        8.1     9.9    10.6
1/8 - MC3E - 10                     1/4 - MC3E - 10                     2.0       2.3       3.2      3.9      4.6      5.0      5.5      6.0      7.1     8.8       10.2    12.5    13.5
1/8 - MC3E - 15                     1/4 - MC3E - 15                     2.4       3.4       4.8      5.9      6.8      7.5      8.3      9.0     10.6    13.0       15.1    18.5    20.0
1/8 - MC3E - 20                     1/4 - MC3E - 20                     2.8       4.5       6.5      7.8      9.0     10.1     11.0     12.0     14.4    17.5       20.0    25.0    27.1
1/8 - MC3E - 30                     1/4 - MC3E - 30                     3.6       6.8       9.5     11.7     13.6     15.0     16.5     17.9     21.0    26.1       30.0    37.1    39.9
1/8 - MC3E - 40                     1/4 - MC3E - 40                     4.0       9.0      12.8     15.7     18.0     20.0     22.0     23.9     29.0    35.0       40.1    50.0    52.9
                                    1/4 - MC3E - 50                     4.4      11.3      16.0     19.5     22.6     24.8     28.0     29.8     36.0    44.1       50.9    62.1    67.0
                                    1/4 - MC3E - 60                     4.8      13.5      19.0     23.0     27.0     30.1     33.2     36.0     43.1    52.9       61.0    74.2    80.0
                                    1/4 - MC3E - 70                     5.2      15.8      22.0     27.0     31.6     34.8     39.0     42.0     50.1    61.0       71.0    86.8    94.0
                                    1/4 - MC3E - 80                     5.4      18.1      26.0     31.0     36.2     40.2     44.0     47.7     57.0    70.1       81.0    99.0   107

3/8 - MC3 - 10                      ✼ 3/8 - MC3E - 10                   2.0       2.3       3.2      3.9      4.6      5.0      5.5      6.0      7.1     8.8       10.2    12.5    13.5
3/8 - MC3 - 15                      ✼ 3/8 - MC3E - 15                   2.4       3.4       4.8      5.9      6.8      7.5      8.3      9.0     10.6    13.0       15.1    18.5    20.0
3/8 - MC3 - 20                      ✼ 3/8 - MC3E - 20                   2.8       4.5       6.5      7.8      9.0     10.1     11.0     12.0     14.4    17.5       20.0    25.0    27.1
3/8 - MC3 - 30                      ✼ 3/8 - MC3E - 30                   3.6       6.8       9.5     11.7     13.6     15.0     16.5     17.9     21.0    26.1       30.0    37.1    39.9
3/8 - MC3 - 40                      ✼ 3/8 - MC3E - 40                   4.0       9.0      12.8     15.7     18.0     20.0     22.0     23.9     29.0    35.0       40.1    50.0    52.9
3/8 - MC3 - 50                      ✼ 3/8 - MC3E - 50                   4.4      11.3      16.0     19.5     22.6     24.8     28.0     29.8     36.0    44.1       50.9    62.1    67.0
3/8 - MC3 - 60                      ✼ 3/8 - MC3E - 60                   4.8      13.5      19.0     23.0     27.0     30.1     33.2     36.0     43.1    52.9       61.0    74.2    80.0
3/8 - MC3 - 70                      ✼ 3/8 - MC3E - 70                   5.2      15.8      22.0     27.0     31.6     34.8     39.0     42.0     50.1    61.0       71.0    86.8    94.0
3/8 - MC3 - 100                     ✼ 3/8 - MC3E - 100                  6.4      23.0      32.0     39.0     46.0     50.0     54.0     60.0     71.0    88.0      100     124     134
3/8 - MC3 - 120                     ✼ 3/8 - MC3E - 120                  7.0      27.0      38.0     46.0     54.0     60.0     66.0     72.0     85.0   105        121     149     160

                         1/2       MC3 - 15                             2.4       3.4       4.8      5.9      8.8      7.5      8.3      9.0     10.8    13.0       15.1    18.5    20.0
                         1/2       MC3 - 50                             4.4      11.3      18.0     19.5     22.6     24.8     28.0     29.8     36.0    44.1       50.9    62.1    67.0
                         1/2       MC3 - 60                             4.8      13.5      19.0     23.0     27.0     30.1     32.2     36.0     43.1    52.9       61.0    74.2    80.0
                         1/2       MC3 - 100                            6.4      23.0      32.0     39.0     46.0     50.0     54.0     60.0     71.0    88.0      100     124     134
                         1/2       MC3 - 150                            7.5      34.0      48.0     59.5     68.0     75.0     83.0     91.0    107     130        152     186     200
                         1/2       MC3 - 200                            8.7      45.0      64.2     75.5     90.0    100      110      120      143     175        200     245     265
                         ✼ 3/4     MC3 - 200                            8.7      45        64       75       90      100      110      120      143     175        200     245      265
                         ✼ 3/4     MC3 - 250                            9.5      56        80       98      112      125      138      149      180     220        250     311      335
                         ✼ 3/4     MC3 - 350                           11.1      79       112      137      158      176      194      210      250     305        356     435      469
                         ✼ 3/4…

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Euspray Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy Euspray MC3E flat jet nozzles in the Philippines?

3G Electric Philippines supplies Euspray MC3E nozzles with delivery to Manila and Quezon City. We handle Bureau of Customs documentation and logistics. Contact us for lead time and PHP quotation on part TEC08006.

What is the flow rate and spray angle of the Euspray MC3E 1/8" nozzle?

The MC3E delivers 3.5 l/min at 20 bar with an 80° flat-fan spray angle. Brass construction, 1/8" connection. Index 04 ensures precise pattern control for industrial cleaning, coating, and humidification.

What applications suit the Euspray MC3E flat jet nozzle?

The 80° flat-fan pattern at 3.5 l/min makes it ideal for industrial cleaning, coating applications, and humidification systems. Brass body resists corrosion in food processing, packaging, and manufacturing environments across CALABARZON.
