Preciman Stainless axial gauge D63 0/+25Mbar G1/4 - Measurement
PrecimanMeasurement

Preciman Stainless axial gauge D63 0/+25Mbar G1/4

Preciman stainless axial gauge measures low pressure in pneumatic systems with 63 mm diameter and G1/4 connection. Delivers ±1.6% full-scale accuracy across 0–25 mbar range. Suits industrial pneumatic applications…

SKU 3G-CBM-06277

Also listed as: ROS 23002 · ROS-23002

Brand
Preciman
Item
Stainless axial gauge D63 0/+25Mbar G1/4
Category
Measurement
UNSPSC
41112412 — Pressure gauge
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineerMessage via Telegram
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Local availability & support — the Philippines

Delivery
5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment
Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to
Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Preciman
case
stainless_steel
size
63 mm
type
capsule_gauge
accuracy
±1.6% of full scale
connection
G1/4
application
low_pressure_pneumatic_systems
wetted parts
copper_alloy
pressure range
0-25 mbar

Datasheet Content

Manomètre ROS20002 à 16 Name : Capsule gauge Application : Low pressure pneumatic systems Suitable for fluid medium, gaseous or dry that does not corrode copper alloy. Low pressure series Copper alloy wetted parts & stainless steel case Specifications : Size : 2.5”(63mm) , 4” (100mm), 6“（150mm） Accuracy : +-1.6% of full scales Range available ( no stock) : 10 "H2O to 240 "H2O (25 to 600 mbar) or other equivalent units of pressure or vacuum Working Pressure : Steady : full scale Fluctuating : 0.9 x full scale Operating Temperature Ambient: -4°F to 140°F (-20°C to +60°C) Media: max. 140°F (+60°C) Service Fluid : compatible gases and liquids Housing: Stainless steel and Bayonet bezel . Windows : glass window . Capsule : Copper- alloy Movement : full-copper alloy Connection : brass 1/8” OR 1/4” for 2.5”(63mm) , 3/8” OR 1/2” for 4” (100mm) , 6”(150mm) Thread : BSP , BSPT, NPT ,or metric thread. Dials: aluminum White background Black or black and red lettering . With customer logo is available . Scale Unit : in. H2O/mm H2O oz.-sq. in./mm H2O oz.-sq. in./in. H2O PSI Optional extras Zero ajustable .

Technical Documents

(1)
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Preciman Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

Preciman stainless axial gauge measures low pressure in pneumatic systems with 63 mm diameter and G1/4 connection. Delivers ±1.6% full-scale accuracy across 0–25 mbar range. Suits industrial pneumatic applications requiring reliable pressure monitoring.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the Preciman ROS23002 axial gauge in the Philippines?

3G Electric Philippines supplies the Preciman ROS23002 stainless axial gauge with delivery to Manila and Quezon City. We handle all logistics, customs clearance, and Bureau of Customs documentation. Contact us for pricing and lead-time confirmation.

What is the lead time for the Preciman ROS23002 gauge?

Lead time on request. 3G Electric sources the Preciman ROS23002 from our network and manages delivery to the Philippines, including customs clearance and PHP invoicing. Submit your order for a confirmed lead-time quote.

What pressure range and accuracy does the Preciman ROS23002 provide?

The Preciman ROS23002 measures 0–25 mbar with ±1.6% full-scale accuracy. It features a 63 mm stainless-steel case, G1/4 male connection, and capsule-gauge design for reliable low-pressure monitoring in pneumatic systems.

Used in

Common applications for Preciman
Boiler steam-system monitoring — Preciman D100 glycerin gauges (0–40 bar) mounted on boiler headers and steam-outlet lines.
Pump discharge pressure indication — Preciman D63 axial stainless gauges (0–250 bar) on centrifugal-pump outlet manifolds and pressure-relief test points.
Compressed-air and vacuum systems — Preciman vacuum and low-range gauges (−1 to +0 bar, 0–1.6 bar) on air-treatment equipment and vacuum pumps.
Hydraulic-circuit monitoring — Preciman all-stainless manometers (D63 vertical, up to 250 bar) on hydraulic-press and industrial-lifting-system manifolds.
Fuel-gas and burner control lines — Preciman D63 low-range gauges (0–1 bar, 0–2.5 bar) on natural-gas and LPG regulator outlet monitoring.
Heat-exchanger and thermal-loop diagnostics — Preciman glycerin D63/D100 gauges for hot-water circulation and process-steam secondary loops.
