Preciman Stainless gauge vertical D63 0/+250Mbar G1/4

Manomètre ROS20002 à 16 Name : Capsule gauge Application : Low pressure pneumatic systems Suitable for fluid medium, gaseous or dry that does not corrode copper alloy. Low pressure series Copper alloy wetted parts & stainless steel case Specifications : Size : 2.5”(63mm) , 4” (100mm), 6“（150mm） Accuracy : +-1.6% of full scales Range available ( no stock) : 10 "H2O to 240 "H2O (25 to 600 mbar) or other equivalent units of pressure or vacuum Working Pressure : Steady : full scale Fluctuating : 0.9 x full scale Operating Temperature Ambient: -4°F to 140°F (-20°C to +60°C) Media: max. 140°F (+60°C) Service Fluid : compatible gases and liquids Housing: Stainless steel and Bayonet bezel . Windows : glass window . Capsule : Copper- alloy Movement : full-copper alloy Connection : brass 1/8” OR 1/4” for 2.5”(63mm) , 3/8” OR 1/2” for 4” (100mm) , 6”(150mm) Thread : BSP , BSPT, NPT ,or metric thread. Dials: aluminum White background Black or black and red lettering . With customer logo is available . Scale Unit : in. H2O/mm H2O oz.-sq. in./mm H2O oz.-sq. in./in. H2O PSI Optional extras Zero ajustable .
