Preciman Stainless steel vertical pressure gauge D63 0/+40Mbar G1/4

Preciman stainless steel vertical pressure gauge for low-pressure industrial monitoring, featuring 63mm dial size and ±1.6% accuracy across 0/+40 mbar range. G1/4 connection with copper alloy wetted parts suits fluid…

SKU 3G-CBM-06260

Also listed as: ROS 20004 · ROS-20004

Brand

Preciman

Item

Stainless steel vertical pressure gauge D63 0/+40Mbar G1/4

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Preciman

size

63mm

accuracy

±1.6% of full scale

connection

G1/4

wetted parts

copper alloy

case material

stainless steel

pressure range

0/+40 mbar

Datasheet Content

Manomètre ROS20002 à 16




Name : Capsule gauge
Application :
Low pressure pneumatic systems
Suitable for fluid medium, gaseous or dry that does not
corrode copper alloy.
Low pressure series
Copper alloy wetted parts & stainless steel case
Specifications :
Size : 2.5”(63mm) , 4” (100mm), 6“（150mm）
Accuracy :
+-1.6% of full scales
Range available ( no stock) :
10 "H2O to 240 "H2O (25 to 600 mbar)
or other equivalent units of pressure or vacuum
Working Pressure :
Steady : full scale
Fluctuating : 0.9 x full scale
Operating Temperature
Ambient: -4°F to 140°F (-20°C to +60°C)
Media: max. 140°F (+60°C)
Service Fluid : compatible gases and liquids
Housing: Stainless steel and Bayonet bezel .
Windows : glass window .
Capsule : Copper- alloy
Movement : full-copper alloy
Connection : brass
           1/8” OR 1/4” for 2.5”(63mm) ,
           3/8” OR 1/2” for 4” (100mm) , 6”(150mm)
Thread : BSP , BSPT, NPT ,or metric thread.
Dials:     aluminum
           White background
           Black or black and red lettering .
           With customer logo is available .
Scale Unit : in. H2O/mm H2O
             oz.-sq. in./mm H2O
             oz.-sq. in./in. H2O
             PSI
Optional extras
Zero ajustable .

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Preciman Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy a Preciman D63 pressure gauge in the Philippines?

Order the Preciman ROS20004 from 3G Electric Philippines. We source and deliver measurement instruments to Manila, Quezon City, and across the Philippines. 3G Electric handles all Bureau of Customs documentation, logistics, and PHP invoicing for fast procurement.

What is the lead time for the Preciman D63 gauge?

Lead time depends on stock availability. Contact 3G Electric Philippines for current availability and delivery schedule. We manage customs clearance and handle full logistics to your facility.

What pressure range and accuracy does the Preciman D63 gauge provide?

The Preciman D63 measures 0/+40 mbar with ±1.6% accuracy across full scale. It features a 63mm stainless steel case, G1/4 connection, and copper alloy wetted parts for fluid system monitoring and process control applications.

Used in

Common applications for Preciman

Boiler steam-system monitoring — Preciman D100 glycerin gauges (0–40 bar) mounted on boiler headers and steam-outlet lines.

Pump discharge pressure indication — Preciman D63 axial stainless gauges (0–250 bar) on centrifugal-pump outlet manifolds and pressure-relief test points.

Compressed-air and vacuum systems — Preciman vacuum and low-range gauges (−1 to +0 bar, 0–1.6 bar) on air-treatment equipment and vacuum pumps.

Hydraulic-circuit monitoring — Preciman all-stainless manometers (D63 vertical, up to 250 bar) on hydraulic-press and industrial-lifting-system manifolds.

Fuel-gas and burner control lines — Preciman D63 low-range gauges (0–1 bar, 0–2.5 bar) on natural-gas and LPG regulator outlet monitoring.

Heat-exchanger and thermal-loop diagnostics — Preciman glycerin D63/D100 gauges for hot-water circulation and process-steam secondary loops.
