Fantini Cosmi Stainless electrode - L.2m 2013348

Fantini Cosmi stainless electrode for temperature monitoring and control in heating systems. Features 2 m cable length and handles temperatures up to 160°C at 10 bar operating pressure, with G 3/8" connection for…

SKU 3G-CBM-03501

Also listed as: FAN 02022 · FAN-02022

Brand

Fantini Cosmi

Item

Stainless electrode - L.2m 2013348

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Fantini Cosmi

connection

G 3/8"

cable length

2 m

max temperature

160°C

max operating pressure

10 bar

Datasheet Content

FAN02012 à 22
temperatures

                                                                                                               .

                                                                        Dimensions (mm)
                                                                                                  60                   G 3/8

FEATURES
Maximum operating pressure: 10 bar.
Maximum temperature: 160 ° C.
Male connection G 3/8”.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code 3G-CBM-03501 Stainless steel electrode AISI 303 - 2 m length.

EA19 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATION.

                                                                                                              Ø 4 мм

                                                                                          16÷20

                                                                        Dimensions (mm)
                                                                                                              70

                                                                                                       Ø 20

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 80°C.
Stainless steel electrode AISI 303 (included).
Cable gland G1/4”.
Connection cable 1x1,5mm2 (not included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
EA20 Stainless steel electronic probe AISI 303
suitable for wells and tanks under pressure and/or for high temperatures.

                                                            Dimensions (mm)
                                                                                    165
                                                                                           G 3/8

                                                                                           3,5

FEATURES
Maximum operating pressure: 35 bar.
Maximum temperature: 250°C.
Male connection G3/8“.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code 3G-CBM-03501 Stainless steel electrode AISI 303 - 2 m length.

EA21 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATIOn.

                                                          Dimensions (mm)
                                                                              160

                                                                                    Ø 25

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 50°C.
6m cable length included.
Stainless steel electrode AISI 316
(included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (6 m).

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Fantini Cosmi Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy a Fantini Cosmi 2013348 stainless electrode in the Philippines?

3G Electric Philippines supplies the Fantini Cosmi 2013348 stainless electrode with delivery to Manila and Quezon City. We handle all logistics, customs documentation, and PHP invoicing. Contact us for lead times and to place an order.

What is the cable length and temperature rating of this electrode?

The Fantini Cosmi 2013348 features a 2 m cable length and is rated for temperatures up to 160°C at a maximum operating pressure of 10 bar. It connects via G 3/8" fitting for standard thermostat integration in heating systems.

Is this electrode compatible with standard heating system thermostats?

Yes. The Fantini Cosmi 2013348 electrode connects via G 3/8" thread, the industry standard for heating system thermostat integration. Its 2 m cable length allows flexible sensor placement in hot water and steam applications up to 160°C.

Used in

Common applications for Fantini Cosmi

Oil-fired boiler burner control — Fantini Cosmi ambient thermostat C16I and pressure switch B12HNY for fuel-pump lockout and room-temperature feedback.

Pneumatic compressor load management — B12DN or B13CN pressure switch for unload-valve control and tank cutout in 5–150 bar air systems.

Hydronic heating-plant commissioning — B12GNY and B12CRNY switches for pump-discharge and low-pressure monitoring in chilled-water and hot-water loops.

Industrial steam and hot-water vessel safety — B12HNY high-pressure switch and A96D/A95B level regulators for water-level and overpressure interlocks.

Thermal-storage tank management — A95B and A96D liquid-level regulators with 15-meter cable reach for boiler-makeup and expansion-tank applications.

Portable pump and pressure-test equipment — B12DN with adjustable differential for mobile hydraulic-circuit monitoring and component proof-pressure validation.
