Fantini CosmiSwitches & Thermostats

Fantini Cosmi Weighted probes PVC 1 electrode EA21

SKU 3G-CBM-03499

Also listed as: FAN 02018 · FAN-02018

Brand

Fantini Cosmi

Item

Weighted probes PVC 1 electrode EA21

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Fantini Cosmi

probe type

ballasted

probe length

160 mm

suitable for

wells, storage tanks, reservoirs for irrigation

probe diameter

25 mm

connection type

single-pole flexible cable

max temperature

50°C

electrode included

yes

electrode material

stainless steel AISI 316

probe body material

PVC

cable length included

6 m

max operating pressure

atmospheric pressure

connection cable supplied

yes

Datasheet Content

FAN02012 à 22
temperatures

                                                                                                               .

                                                                        Dimensions (mm)
                                                                                                  60                   G 3/8

FEATURES
Maximum operating pressure: 10 bar.
Maximum temperature: 160 ° C.
Male connection G 3/8”.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code FAN02022 Stainless steel electrode AISI 303 - 2 m length.

EA19 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATION.

                                                                                                              Ø 4 мм

                                                                                          16÷20

                                                                        Dimensions (mm)
                                                                                                              70

                                                                                                       Ø 20

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 80°C.
Stainless steel electrode AISI 303 (included).
Cable gland G1/4”.
Connection cable 1x1,5mm2 (not included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
EA20 Stainless steel electronic probe AISI 303
suitable for wells and tanks under pressure and/or for high temperatures.

                                                            Dimensions (mm)
                                                                                    165
                                                                                           G 3/8

                                                                                           3,5

FEATURES
Maximum operating pressure: 35 bar.
Maximum temperature: 250°C.
Male connection G3/8“.

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (not supplied).
Electrode probe is not supplied as well.

ACCESSORIES
code FAN02020 Stainless steel electrode AISI 303 - 1 m length.
code FAN02022 Stainless steel electrode AISI 303 - 2 m length.

EA21 Ballasted PVC probe with electrode
SUITABLE FOR WELLS, storage tanks and reservoirs FOR IRRIGATIOn.

                                                          Dimensions (mm)
                                                                              160

                                                                                    Ø 25

FEATURES
Operation at atmospheric pressure.
Maximum temperature: 50°C.
6m cable length included.
Stainless steel electrode AISI 316
(included).

INSTALLATION
Connection between the probe and the level control is realized through a single-pole flexible cable (6 m).

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Fantini Cosmi Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Fantini Cosmi Weighted probes PVC 1 electrode EA21

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the Fantini Cosmi EA21 weighted probe in the Philippines?

3G Electric Philippines supplies the Fantini Cosmi EA21 probe with delivery to Manila and Quezon City. We handle Bureau of Customs documentation, logistics coordination, and PHP invoicing for procurement orders. Lead time on request.

What is the lead time for delivery of the EA21 probe to the Philippines?

The EA21 probe is available to order. Exact lead time depends on current inventory and freight routing. Contact 3G Electric Philippines for a specific delivery quote — we manage all customs and logistics to your site.

Is the Fantini Cosmi EA21 probe suitable for irrigation storage tanks?

Yes. The EA21 is a 160 mm ballasted probe designed for wells, storage tanks, and irrigation reservoirs. It includes a 6 m flexible cable with stainless steel AISI 316 electrode. Maximum temperature rating is 50°C and operating pressure is atmospheric.
