DSZH Plastic tube kit to bend CLIMACONCEPT

DSZH plastic tube bending kit for CLIMACONCEPT air conditioning systems handles four tube sizes from 1/4" (4mm) to 5/8" (12mm). Essential HVAC installation tool for precision copper tube bending in refrigeration and…

SKU 3G-CBM-01531

Also listed as: COR 35803 · COR-35803

Brand

DSZH

Item

Plastic tube kit to bend CLIMACONCEPT

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

DSZH

material

plastic

tube sizes

1/4" (4mm), 3/8" (7mm), 1/2" (9mm), 5/8" (12mm)

application

air conditioning tube bending kit

Datasheet Content

3G-CBM-01531
                              Kit tubes
                     Air Condition  Lineà Set
                                          cintrer
                                              Bender Kit
  Manuel :
 Lisez toutes les instructions et les mises en garde avant d'utiliser ce produit.
 Les WXEHV à cintrer ont été conçu pour réaliser des cintrages un par un.
 Lors de l'installation d'un réseau complexe comportant de nombreux cintrages,
 torsions ou coudes, veuillez respecter les recommandations suivantes pour
 faciliter le retrait du tube une fois tous les cintrages effectués :


 1. Insérez les tubes du kit à cintrer à au moins 30 cm au-delà du point où vous
    commencerez à faire votre premier cintrage.
 2. Toujours commencer par le cintrage le plus éloigné du condenseur (unité
    extérieure).
 3. Retirez le(s) tube(s) jusqu'au prochain cintrage, en vous assurant qu'il reste
    encore au moins 30 cm au-delà du point de pliage de votre prochain cintrage
    (c'est-à-dire plus près du cintrage précédent).
 4. Répétez le processus jusqu'à ce que vous ayez réalisé tous les pliages, le
    dernier étant le plus proche du condenseur (unité extérieure).

Ignorer les instructions ci-dessus peut entraîner des difficultés lors du
retrait des tubes et entraîner leur déformation ou leur rupture.


 Couleur         Diamètre           Taille du tube
 Rouge            4 mm                     1/4"
  Vert               7 mm                  3/8"
  Jaune              9 mm                  1/2"
  Bleu            12 mm                    5/8"

 Avantages :
   Pas besoin de ressorts métalliques et les matériels lourds et coûteux.
   Tubes flexibles.
   Fini les liaisons pincées.
   Produits réutilisables et fait en matériaux durables.
   4 tailles pour la plupart des applications.
   Longueur tube : 4 m.



                 1                            2                             3

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

DSZH Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the DSZH COR35803 tube bending kit in the Philippines?

Source the DSZH COR35803 from 3G Electric Philippines. We deliver to Manila, Quezon City, and CALABARZON. 3G Electric handles Bureau of Customs documentation, Philippine logistics, and quotations in PHP. Contact us for lead times and pricing.

What tube sizes does this CLIMACONCEPT bending kit handle?

The DSZH COR35803 bends four copper tube sizes: 1/4" (4mm), 3/8" (7mm), 1/2" (9mm), and 5/8" (12mm). Ideal for refrigeration and air conditioning installation work across residential and commercial systems.

What is the lead time for ordering the DSZH COR35803 in the Philippines?

Lead time on request. 3G Electric sources the DSZH COR35803 as an available-to-order item. Contact us with your delivery address in the Philippines for a firm quote, expected arrival date, and total landed cost including customs and freight to Manila or Quezon City.

Used in

Common applications for DSZH

Split-system air-conditioner service: DSZH manifold bases and SAE/NPT reducers integrate with technician gauge sets for pressure monitoring and refrigerant charge.

Rooftop packaged unit maintenance: Flare connector caps, hose tips, and union fittings expedite field replacement of damaged lines and adapters on commercial cooling systems.

Refrigerant recovery and recycling: DSZH bottle adapters (R600A-rated) connect recovery cylinders to hose lines, enabling safe extraction of flammable and standard refrigerants.

Process-cooling loop installation: SAE straight male/female unions and reducers support temporary or permanent manifold assembly on industrial water-chilled equipment.

Heat-pump seasonal service: DSZH dudgeon extensions and adapter kits allow technicians to connect diagnostic gauges to restricted or recessed access ports on reversing-valve manifolds.

Field emergency repairs: Individual DSZH fittings stocked in stock allow technicians to repair or modify hose connections on-site without returning to the shop for components.
