ASHCROFT Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
ASHCROFTPressure Transmitters with 4-Pin M12 Connector

ASHCROFT Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEA0) is a 0 psi to 1,000 psi pressure transmitter with a 4-Pin M12 Connector. It features a 4 to 20mA DC output, ±0.5% accuracy, and an IP67 / NEMA 4X rating. The…

SKU 3G-OTH-176725

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42EW1000#
Series
G2
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
Male SAE
7/16 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
M12 Connector
4-Pin
Burst Pressure
5x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEA0) is a 0 psi to 1,000 psi pressure transmitter with a 4-Pin M12 Connector. It features a 4 to 20mA DC output, ±0.5% accuracy, and an IP67 / NEMA 4X rating. The nylon housing includes a 7/16 in Male SAE process connection, with overpressure of 2x range and burst pressure of 5x range.
