APPROVED VENDOR Key Locking Insert: Extra Heavy Wall, 4 Keys, 1/2"-20 Int Thrd Sz, 13/16"-16 Ext Thrd Sz - Mil. Spec. Key-Locking Inserts
APPROVED VENDORMil. Spec. Key-Locking Inserts

APPROVED VENDOR Key Locking Insert: Extra Heavy Wall, 4 Keys, 1/2"-20 Int Thrd Sz, 13/16"-16 Ext Thrd Sz

The APPROVED VENDOR Key Locking Insert is a Mil. Spec. key-locking insert with an Extra Heavy Wall, supplied in a 10 PK. It features 4 keys, a 1/2"-20 internal thread size, a 13/16"-16 external thread size, and meets…

SKU 3G-OTH-531767

Brand
APPROVED VENDOR
Item
Key Locking Insert: Extra Heavy Wall, 4 Keys, 1/2"-20 Int Thrd Sz, 13/16"-16 Ext Thrd Sz
Category
Mil. Spec. Key-Locking Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
217-077538
Type
10 PK
Keys
4
Wall Type
Extra Heavy Wall
Ext Thrd Sz
13/16"-16
Finish Type
Plain
Int Thrd Sz
1/2"-20
Thread Type
Coarse
Industry Standards
MS51832-206L
Compatible Tap Size
13/16"-16
External Thread Fit
2A
Internal Thread Fit
3B
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Key Locking Insert is a Mil. Spec. key-locking insert with an Extra Heavy Wall, supplied in a 10 PK. It features 4 keys, a 1/2"-20 internal thread size, a 13/16"-16 external thread size, and meets MS51832-206L. Made from 18-8 material with a Plain finish, it has an external thread fit of 2A and internal thread fit of 3B.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR Key Locking Insert used for?

This Mil. Spec. key-locking insert repairs or reinforces tapped holes in metal assemblies, especially where vibration could loosen standard threads. The extra heavy wall and 4 keys provide high pull-out resistance. It is commonly used in aerospace, defense, and industrial equipment requiring MS51832-206L compliance.

What are the specifications of the APPROVED VENDOR Key Locking Insert 217-077538?

This 10-pack insert has a 1/2"-20 internal thread and 13/16"-16 external thread, with an extra heavy wall. It is made from 18-8 stainless steel, plain finish, with external thread fit 2A and internal thread fit 3B. It meets Mil. Spec. MS51832-206L and requires a 13/16"-16 tap.

Where to buy APPROVED VENDOR Key Locking Inserts worldwide?

3G Electric supplies APPROVED VENDOR key locking inserts to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. As a global industrial sourcing partner, we provide genuine Mil. Spec. inserts like the 217-077538 with 18-8 material and extra heavy wall construction.

How to install an APPROVED VENDOR Key Locking Insert?

First, tap the hole to the compatible tap size (13/16"-16 for this insert). Then, screw the insert into the tapped hole using a key-locking insert installation tool. After installation, the 4 keys are set into the parent material to prevent rotation. Use a thread locking compound for critical applications.
