APPROVED VENDOR Key Locking Insert: Thin Wall, 4 Keys, M10x1.25 Int Thrd Sz, M14x1.5 Ext Thrd Sz - Mil. Spec. Key-Locking Inserts
APPROVED VENDORMil. Spec. Key-Locking Inserts

APPROVED VENDOR Key Locking Insert: Thin Wall, 4 Keys, M10x1.25 Int Thrd Sz, M14x1.5 Ext Thrd Sz

The APPROVED VENDOR Key Locking Insert is a thin-wall, mil. spec. insert with 4 keys, M10x1.25 internal thread size, M14x1.5 external thread size, plain finish, and 18-8 material. It meets Fed Std. H28/21 and MJ Form…

SKU 3G-OTH-531696

Brand
APPROVED VENDOR
Item
Key Locking Insert: Thin Wall, 4 Keys, M10x1.25 Int Thrd Sz, M14x1.5 Ext Thrd Sz
Category
Mil. Spec. Key-Locking Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
217-077555
Type
M10x1.25 Int Thrd Sz, M14x1.5 Ext Thrd Sz, Plain, 10 PK
Keys
4
Wall Type
Thin Wall
Finish Type
Plain
Thread Type
Coarse
Industry Standards
Fed Std. H28/21, MJ Form
Compatible Tap Size
M14x1.5
External Thread Fit
2A
Internal Thread Fit
3B
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Key Locking Insert is a thin-wall, mil. spec. insert with 4 keys, M10x1.25 internal thread size, M14x1.5 external thread size, plain finish, and 18-8 material. It meets Fed Std. H28/21 and MJ Form standards, with external thread fit 2A and internal thread fit 3B, compatible with M14x1.5 tap size. Supplied in a 10-pack (MPN 217-077555).

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a key locking insert used for?

A key locking insert is used to repair or reinforce tapped threads in metal assemblies, especially in aerospace and defense applications. The APPROVED VENDOR thin-wall insert with 4 keys provides a permanent, high-strength thread that meets Fed Std. H28/21 and MJ Form standards for critical fastening.

What are the specifications of the APPROVED VENDOR key locking insert?

This thin-wall insert has M10x1.25 internal thread, M14x1.5 external thread, 4 keys, plain finish, and 18-8 material. It meets Fed Std. H28/21 and MJ Form standards, with external thread fit 2A and internal thread fit 3B. Compatible tap size is M14x1.5. Supplied in a 10-pack (MPN 217-077555).

Where to buy APPROVED VENDOR key locking inserts worldwide?

3G Electric supplies APPROVED VENDOR key locking inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the 10-pack (MPN 217-077555) or other mil. spec. inserts for your application.

How to install a thin-wall key locking insert?

Installation requires tapping the hole to the specified compatible tap size (M14x1.5), then driving the insert using a key locking insert tool until it is flush or slightly below the surface. The 4 keys lock the insert in place. Follow standard mil. spec. practices for thread repair to ensure proper fit and strength.
