APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert for metal, supplied in a 5-pack. It features a 7/16"-20 fine thread, 18-8 material grade, and a tensile strength of 200,000 psi. This…

SKU 3G-OTH-528999

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-7/16X2.0DSL
Type
Screw-Locking, Plain, 5 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Size
7/16"-20
Thread Type
Fine
STI Tap Size
7/16"-20
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert for metal, supplied in a 5-pack. It features a 7/16"-20 fine thread, 18-8 material grade, and a tensile strength of 200,000 psi. This inch-system insert is right-hand threaded and compatible with metal substrates.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or reinforces threads in metal components. It is used in automotive, aerospace, and industrial machinery to restore stripped threads or provide stronger threads in softer materials. The screw-locking design resists vibration loosening.

What are the specifications of the APPROVED VENDOR 3534-7/16X2.0DSL helical insert?

This helical insert has a 7/16"-20 fine thread, 18-8 material grade, and 200,000 psi tensile strength. It is a screw-locking, tanged tang style, plain finish, right-hand thread, and compatible with metal. Supplied in a 5-pack by APPROVED VENDOR.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this 7/16"-20 screw-locking insert. We source genuine industrial parts across 14 departments.

How to install a tanged tang helical insert?

Install using a compatible STI tap (7/16"-20) to prepare the hole. Insert the tang into the driver tool and wind the insert into the tapped hole until it sits below the surface. After installation, break off the tang with a punch. Always follow the manufacturer's generic installation guidelines.
