APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 1 in Trade Size, L Body - L Round Body - 90° Elbow Type
APPLETON ELECTRICL Round Body - 90° Elbow Type

APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 1 in Trade Size, L Body

The APPLETON ELECTRIC GRL100 is a 1-inch trade size, L-style conduit outlet body made of iron with a triple coat epoxy coating. This 90° elbow type body has a round back, threaded female hubs, and an 18 cu in…

SKU 3G-OTH-05093

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, GR, 1 in Trade Size, L Body
Category
L Round Body - 90° Elbow Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GRL100
Series
For Standard Body
Material
Iron
Finish
Triple Coat Epoxy Coating
Includes
Grounding Screw
Back Type
Round
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
UL Listed for Class I, Division 1 and 2, Groups B, C, D, Class II, Division 1 and 2, Groups E, F, G, and Class III
Body Style
L
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Hazardous Location
Yes
Compatible Conduit Trade Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC GRL100 is a 1-inch trade size, L-style conduit outlet body made of iron with a triple coat epoxy coating. This 90° elbow type body has a round back, threaded female hubs, and an 18 cu in capacity, and includes a grounding screw and cover. It is UL Listed for hazardous locations, including Class I, Division 1 and 2, Groups B, C, D, Class II, Division 1 and 2, Groups E, F, G, and Class III, and is designed for use with threaded IMC.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Appleton Electric GRL100 conduit outlet body used for?

The Appleton Electric GRL100 is a 1-inch L-style conduit outlet body used to provide a pull point or junction in threaded rigid metal conduit (IMC) systems. Its iron construction and triple coat epoxy coating make it suitable for hazardous locations, including Class I, Division 1 and 2, Groups B, C, D.

What are the specifications of the Appleton Electric GRL100?

The Appleton Electric GRL100 is a 1-inch trade size, L-body conduit outlet body with threaded female hubs, a round back, and 18 cu in capacity. It is made of iron with a triple coat epoxy coating, includes a grounding screw and cover, and is UL Listed for hazardous locations.

Where to buy the Appleton Electric GRL100 in worldwide?

3G Electric supplies the Appleton Electric GRL100 conduit outlet body to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this UL Listed, hazardous-location-rated fitting.

How to install the Appleton Electric GRL100 conduit outlet body?

Install the Appleton Electric GRL100 by threading it onto threaded IMC conduit using the female hubs. Ensure the cover is securely fastened and the grounding screw is connected per local electrical codes. For hazardous locations, follow NEC requirements for sealing and bonding.
