AIGNEP USA Push-Fit Elbow Fitting: 3/8 in OD x 3/8 in Pipe Size - Nylon & Nickel-Plated Brass Tube Fittings
AIGNEP USANylon & Nickel-Plated Brass Tube Fittings

AIGNEP USA Push-Fit Elbow Fitting: 3/8 in OD x 3/8 in Pipe Size

The AIGNEP USA Push-Fit Elbow Fitting is a nylon and nickel-plated brass tube fitting with a 3/8 in OD x 3/8 in Pipe Size, Push-to-Connect x Universal Thread configuration (MPN 85110-06-06). It features a Thread Size…

SKU 3G-OTH-491930

Brand
AIGNEP USA
Item
Push-Fit Elbow Fitting: 3/8 in OD x 3/8 in Pipe Size
Category
Nylon & Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
85110-06-06
Type
Push-to-Connect x Universal Thread
Thread Size A
3/8-18
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Push-Fit Elbow Fitting is a nylon and nickel-plated brass tube fitting with a 3/8 in OD x 3/8 in Pipe Size, Push-to-Connect x Universal Thread configuration (MPN 85110-06-06). It features a Thread Size A of 3/8-18.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the AIGNEP USA Push-Fit Elbow Fitting used for?

This AIGNEP USA Push-Fit Elbow Fitting connects 3/8 in OD tubing to a 3/8 in male pipe thread in pneumatic or fluid-handling systems. It is commonly used in industrial automation, packaging, and material handling applications where a reliable, leak-free push-to-connect joint is required.

What are the specifications of the AIGNEP USA Push-Fit Elbow Fitting?

The AIGNEP USA Push-Fit Elbow Fitting (MPN 85110-06-06) has a 3/8 in OD tube connection and a 3/8-18 male thread. It is a Push-to-Connect x Universal Thread type, made from nylon and nickel-plated brass. The thread size A is 3/8-18.

Where to buy the AIGNEP USA Push-Fit Elbow Fitting worldwide?

3G Electric supplies the AIGNEP USA Push-Fit Elbow Fitting (MPN 85110-06-06) to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this nylon and nickel-plated brass fitting.

How to install the AIGNEP USA Push-Fit Elbow Fitting?

To install the AIGNEP USA Push-Fit Elbow Fitting, cut the 3/8 in OD tubing square, deburr the end, and push it fully into the fitting until it stops. For the threaded end, apply thread sealant to the 3/8-18 male thread and tighten to the port. Ensure the system is depressurized before installation.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
