AIGNEP USA Push-Fit Elbow Fitting: 1/4 in OD x 1/4 in Pipe Size - Nylon & Nickel-Plated Brass Tube Fittings
AIGNEP USANylon & Nickel-Plated Brass Tube Fittings

AIGNEP USA Push-Fit Elbow Fitting: 1/4 in OD x 1/4 in Pipe Size

The AIGNEP USA Push-Fit Elbow Fitting is a nylon and nickel-plated brass tube fitting with a Push-to-Connect x Universal Thread configuration. It connects 1/4 in OD tubing to a 1/4 in pipe size with a 1/4-18 thread…

SKU 3G-OTH-492537

Brand
AIGNEP USA
Item
Push-Fit Elbow Fitting: 1/4 in OD x 1/4 in Pipe Size
Category
Nylon & Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
85110-04-04
Type
Push-to-Connect x Universal Thread
Thread Size A
1/4-18
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Push-Fit Elbow Fitting is a nylon and nickel-plated brass tube fitting with a Push-to-Connect x Universal Thread configuration. It connects 1/4 in OD tubing to a 1/4 in pipe size with a 1/4-18 thread size (MPN 85110-04-04).

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the AIGNEP USA Push-Fit Elbow Fitting used for?

This AIGNEP USA Push-Fit Elbow Fitting connects 1/4 in OD tubing to a 1/4 in pipe thread in pneumatic or fluid-handling systems. It is commonly used in industrial automation, packaging, and material handling applications where a reliable, leak-free connection is needed.

What are the specifications of the AIGNEP USA 85110-04-04 fitting?

The AIGNEP USA 85110-04-04 is a Push-to-Connect x Universal Thread elbow fitting. It accepts 1/4 in OD tubing and has a 1/4-18 thread size. The body is made of nylon and nickel-plated brass, offering corrosion resistance and durability in industrial environments.

Where to buy AIGNEP USA push-fit fittings worldwide?

3G Electric supplies AIGNEP USA push-fit fittings like the 85110-04-04 to customers worldwide. We handle full logistics and customs clearance, ensuring delivery to your facility. Contact us for a quote and lead time on this nylon and nickel-plated brass elbow fitting.

How to install an AIGNEP USA push-to-connect elbow fitting?

To install the AIGNEP USA push-fit elbow, cut tubing square, deburr, and push fully into the fitting until it stops. For the threaded end, apply sealant to the 1/4-18 thread and tighten to the port. Ensure tubing is fully seated to prevent leaks.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
