AIGNEP USAMini Brass Ball Valves

AIGNEP USA Manual Two-Way Ball Valve: 1/8 in, Nickel-Chrome Plated Brass, Straight

The AIGNEP USA Manual Two-Way Ball Valve is a mini brass ball valve with a 1/8 in connection, featuring a nickel-chrome plated brass body and a wedge handle. It has a straight configuration with MNPT x Push…

SKU 3G-OTH-443691

Brand

AIGNEP USA

Item

Manual Two-Way Ball Valve: 1/8 in, Nickel-Chrome Plated Brass, Straight

Technical Specifications

AIGNEP USA

Manufacturer Part Number

86330-04-02

Type

Nickel-Chrome Plated Brass, Straight, MNPT x Push

Handle

Wedge

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

AIGNEP USA Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the AIGNEP USA Manual Two-Way Ball Valve used for?

This mini brass ball valve is used to start, stop, or redirect fluid flow in pneumatic or low-pressure liquid systems. Its 1/8 in MNPT x Push connections suit compact instrumentation panels, control cabinets, and small-bore tubing applications where reliable manual shut-off is needed.

What are the specifications of the AIGNEP USA 86330-04-02 ball valve?

The AIGNEP USA 86330-04-02 is a manual two-way ball valve with a 1/8 in connection, nickel-chrome plated brass body, straight configuration, and wedge handle. It uses MNPT x Push fittings. This mini valve is designed for compact industrial fluid control systems.

Where to buy the AIGNEP USA 86330-04-02 ball valve worldwide?

3G Electric supplies the AIGNEP USA 86330-04-02 manual ball valve worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this mini brass ball valve.

How to install the AIGNEP USA manual ball valve?

Install the AIGNEP USA ball valve by connecting the male NPT thread to a matching female port and pushing the tubing into the push-fit connector. Ensure the wedge handle is accessible for operation. Use thread sealant on the NPT side and verify tubing is fully seated before pressurizing.

Used in

Common applications for AIGNEP USA

Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.

Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.

Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.

Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.

Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.

Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.

AIGNEP USA Products

3G Electric supplies AIGNEP USA mini brass ball valves. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
