AIGNEP USA Metal Pipe Elbow: 90° Elbow, 1/4 in x 1/4 in - Nickel-Plated Threaded Low-Pressure Pipe Fittings
AIGNEP USANickel-Plated Threaded Low-Pressure Pipe Fittings

AIGNEP USA Metal Pipe Elbow: 90° Elbow, 1/4 in x 1/4 in

The AIGNEP USA Metal Pipe Elbow is a 90° elbow, a nickel-plated threaded low-pressure pipe fitting with 1/4 in x 1/4 in Female NPT Threaded x Female NPT Threaded connections (MPN 82510N-04). It has a maximum…

SKU 3G-OTH-459591

Brand
AIGNEP USA
Item
Metal Pipe Elbow: 90° Elbow, 1/4 in x 1/4 in
Category
Nickel-Plated Threaded Low-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
82510N-04
Type
1/4 in x 1/4 in, Female NPT Threaded x Female NPT Threaded
Maximum Operating Pressure
250 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Metal Pipe Elbow is a 90° elbow, a nickel-plated threaded low-pressure pipe fitting with 1/4 in x 1/4 in Female NPT Threaded x Female NPT Threaded connections (MPN 82510N-04). It has a maximum operating pressure of 250 psi.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the AIGNEP USA 82510N-04 metal pipe elbow used for?

The AIGNEP USA 82510N-04 is a 90° elbow used to change direction in low-pressure piping systems. It connects two 1/4 in female NPT threaded lines, making it suitable for pneumatic, lubrication, or fluid-handling applications where a compact, corrosion-resistant nickel-plated fitting is required.

What are the specifications of the AIGNEP USA 82510N-04?

The AIGNEP USA 82510N-04 is a 90° elbow with 1/4 in x 1/4 in Female NPT Threaded x Female NPT Threaded connections. It has a maximum operating pressure of 250 psi and is made of nickel-plated metal. The manufacturer part number is 82510N-04.

Where to buy the AIGNEP USA 82510N-04 worldwide?

3G Electric supplies the AIGNEP USA 82510N-04 metal pipe elbow to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this nickel-plated 90° elbow.

How to install the AIGNEP USA 82510N-04 elbow?

Install the AIGNEP USA 82510N-04 by applying thread sealant to the male NPT threads and hand-tightening the female connections. Use a wrench on the fitting's hex flats to snug the joint without over-torquing. Do not exceed the 250 psi maximum operating pressure.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
